Description
On Module Feature:
| CPU | i.MX 8M Quad: 4 x Cortex-A53, 1 x Cortex-M4, GPU & VPU i.MX 8M QuadLite: 4 x Cortex-A53, 1 x Cortex-M4 & GPU i.MX 8M Dual: 2 x Cortex-A53 , 1 x Cortex-M4, GPU & VPU |
|---|---|
| Memory & Storage | 2GB LPDDR4 expandable up to 4GB 8GB eMMC Flash expandable up to 128GB QSPI Flash (Optional) Micro SD slot (Optional) |
| Other | IEEE 802.11a/b/g/n/ac/ax Wi-Fi & Bluetooth 5.0 (ax is optional) |
Edge Connector Features:
|
Expansion Connector Features (Optional):
|
OS Support:
|
General Features:
| Power Input | 5V, 2.5A through SMARC Edge Connector |
|---|---|
| Form Factor | 82mm x 50mm |
| Operating Temperature | -40°C to +85°C (Industrial) 0°C to +70°C (Commercial) |
| Environment Specification | REACH & RoHS3 Compliant |
Note: Optional features are not supported in default configuration.
DEVELOPMENT KIT
- Gigabit Ethernet Jack x2
- PCIe x1 or Mini PCIe or M.2 slot
- USB 3.0 Type-A or Type-C
- USB 2.0 Host Type-A x2
- USB 2.0 OTG Type-micro AB x1 (optional)
- Standard SD x1 (Optional)
- HDMI 2.0 /DP1.3 x1
- 5.5” 1080p MIPI DSI display with Capacitive Touch
- 20pin LVDS Connector (Optional)
- MIPI CSI Camera Connector
- Audio In/Out Jack through I2S Codec x1
- Full Function UART – 1 Port
- RTC with backup battery
- CAN Header x2 (Optional)
- Debug UART through Micro USB Port
